Polyurethane injection molding machine FD-2A

Polyurethane injection molding machine FD-2A

Motorized polyurethane injection machine with high working efficiency and good stability

input voltage:220V single-phase, 220V three-phase, 380V three-phase
Power (kW):10
Maximum working pressure:15MPa (150 bar)
Min. Order:1 pieces

Product Details

Important attributes

Video Factory Inspection
available
Mechanical test report
available
warranty period
biennial
Weight (KG)
130 KG
Dimensions (L×W×H)
680*683 *674mm
core component
Bearings, motors, pumps, gears, PLC, pressure vessels, engines
Power (kW)
10
accreditation
ce
Provide after-sales service
Video Technical Support
Conveying Hose
1.5m (5 feet)
Than A and B
1 : 1
material temperature
88 °C (190 °F)
Maximum working pressure
15MPa (150 bar)
air supply
≥0.25m³/min
Maximum Hose Length
45m
Heater power
3000W×2

standard configuration

main frame
1 set
Spray gun (P2 type)
1 set
transfer pump
2 sets (E10 not included)
Heated hoses
15m (49.2ft)
Supply hose (from transfer pump to machine)
2 (1.5 m)
Whip Hose
1 root
air duct
1 set
Tools and spare parts
1 set
English User Manual
1 set

Designed for building construction, home improvement and industrial spraying, this electric polyurethane injector is compact and lightweight, flexible and easy to operate, and can be dosed for precise attention. Whether it is a narrow balcony, pipeline or large industrial equipment injection, can easily cope with. The efficient electric drive system ensures accurate and stable material discharge and greatly improves construction efficiency, making it the ideal choice for users who pursue high-quality construction and high-efficiency work.

Product Highlights

  • Compact and portable: easy to carry and operate in small spaces.

  • Efficient discharging: high transmission efficiency, stable discharging, material saving, faster construction.

  • Simple operation: one key to start, instant start, professional effect, zero threshold use.

  • Durable and reliable: high-quality core components, long-term use is still stable.

  • Low noise and low consumption: energy saving and environmental protection, indoor operation without disturbing people.

Applicable scenes

  • Home construction: balcony, pipe insulation, waterproofing and leakage repair.

  • Industrial production: equipment sealing, parts injection

  • Special engineering: precision injection, narrow space construction.
