FD-511 min

FD-511 min

Based on the min version of the FD-511, we have used a new design to reduce the size of the unit while maintaining the same overall power.

input voltage:220V three-phase, 380V three-phase
Power (kW):21KW
maximum output:2 - 24 kg/min
Maximum working pressure:25MPa (250 bar)
Sample Price:USD $5500-6200
Min. Order:1 pieces

Product Details

Important attributes

Raw material viscosity range (at operating temperature)
200 - 1000 CPS (at operating temperature)
Maximum Fluid Temperature
0 - 88 °C (190 °F)
maximum output
2 - 24 kg/min
Maximum heated hose length
Standard 90 meters (customizable to 150 meters)
Single heater power
8000W×2
Single heater power
8000W×2
core component
Motors, Pumps, PLC, Pressure Vessels, Engines
Gun Type
Spray/Injection
color
Custom Colors
Raw material data ratios
1 : 1
Maximum Fluid Temperature
0 - 88 °C (190 °F)
Maximum heated hose length
Standard 60 meters (customizable to 90 meters)
Heater power
6000W×2
air supply
≥0.25m³/min

standard configuration

main frame
1 set
Spray gun (P2 type)
1 set
transfer pump
2 sets (E10HP not included)
Heated hoses
15m (49.2ft)
Supply hose (from transfer pump to machine)
2 (1.5 m)
Whip Hose
1 root
air duct
1 set
Tools and spare parts
1 set
English User Manual
1 set

Packaging and shipping information

sales unit
Single item
Packaging Details
plywooden boxes
port of embarkation
qingdao

Core application range

  • Proportioning requirements: For polyurethane/polyurea systems with a liquid ratio of 1:1.

  • Manufacturing: Can be used for injection molding of polyurethane products.

  • Thermal insulation scenarios:

    • Wall and roof insulation of residential buildings;

    • Insulation of cold storage facilities (e.g. cold storage, refrigerated trucks), livestock breeding buildings, hanger structures;

    • Insulation of basements, screeds, granaries, silos and other special applications.

  • Sealing and protection: can be used for roof sealing, vehicle chassis spray protection, etc..

  • Other: can be expanded to other polyurethane/polyurea materials for spraying or injection application according to specific needs.


This equipment realizes precise material conveying and mixing through hydraulic drive, and is suitable for heat preservation, sealing and product processing in many fields, with both efficiency and adaptability, and is one of the key equipment for polyurethane material construction and production.
